Horizon MIC 2.K Bulk Wire - Microphone, 2 Conductor (Spool of 500'/1000') - Priced by the Foot
The MIC-2.K roll of 2-conductor, 22 AWG, stranded bare copper, polypropylene insulated, aluminum/polyester tape shield, PVC jacketed microphone wire.
Specifications:
- Conductor Gauge: (2) 22 gauge
- Shield: Bare aluminium/polyester tape
- Shield Coverage: 95%
- O.D.: 0.140"
- Capacitance: 32 pF/ft. @ 1 kHz
- Characteristic Impedance: 45 Ohms Nominal
- D.C. Resistance @ 20 degrees C: 15.3 Ohms/1000 ft.
